Machine line up Portable type JD series
Easy operations covering wide applications.
High efficiency taping operations.
Taping operations with efficiency several higher than manual operations are ensured.
The patented mechanism features trouble-free tape feeding.
The heat-sealing system functions smooth taping of various products.
Sub-materials like glues, hot melts, etc. are not used so that the banded products are kept clean and tidy.
The single-winding system results in low cost operations.
This table top design with light weight is ideal for locatingdesired.
catalogs(PDF file)
instruction manual(PDF file)
Portable type JDⅡ series (for paper tapes only)
| CAPABILITY | ||
| Model | Product size | Speed |
| JDⅡ-240 | Max. (width 240mm, height 170mm) Min. (width 30mm, height 5mm) |
25 cycles/minute (approx.) |
| MACHINE SPECIFICATIONS | ||
| Model-Tape width (mm) | JDⅡ-240-20/25/30 | JDⅡ-240-40 |
| Width | 425mm | 435mm |
| Height | 400mm | 400mm |
| Depth | 287mm | 300mm |
| Table height | 230mm | 230mm |
| Power supply | 115V/220V/230V/240V 50Hz/60Hz |
115V/220V/230V/240V 50Hz/60Hz |
| Allowable tape | Paper tapes | Paper tapes |
| COM TAPE SPECIFICATIONS | ||
| Type | Width | Thickness |
| Paper | 20mm/25mm/30mm/40mm | 70g (brown)/80g (white) |
JDⅡ-150F (film tapes only)
| CAPABILITY | ||
| Model | Product size | Speed |
| JDⅡ-150F | Max. (width 150mm, height 140mm) Min. (width 30mm, height 5mm) |
25 cycles/minute (approx.) |
| MACHINE SPECIFICATIONS | ||
| Model-Tape width (mm) | JDⅡ-150F-20/30 | JDⅡ-150F-40 |
| Width | 425mm | 435mm |
| Height | 400mm | 400mm |
| Depth | 287mm | 300mm |
| Table height | 230mm | 230mm |
| Power supply | 115V/220V/230V/240V 50Hz/60Hz |
115V/220V/230V/240V 50Hz/60Hz |
| Allowable tape | film | film |
| COM TAPE SPECIFICATIONS | ||
| Type | Width | Thickness |
| Film | 20mm/30mm/40mm | 80μ/100μ/110μ magic cut |
